Impulse PinPointR

The PinPointR has been developed to maximize in-field productivity by utilizing ImpulseRadar’s innovative real-time sampling (RTS) dual-channel antenna technology, which provides incredible bandwidth, speed, and resolution, all controlled via an intuitive Android-driven user interface.

The ImpulseRadar PinPointR offers a clear and dependable way to quickly and easily locate, avoid or map underground utilities with the functionality required to meet approved industry standards, whilst offering market-leading performance and data quality.

Detect, Avoid and Map Underground Utilities

Antenna

Technology

ImpulseRadar real-time sampling

Antenna type

PinPointR dual-channel

Centre frequency

CH-1: 400 MHz (LF) / CH-2: 800 MHz (HF)

Channel activation

CH-1 & CH-2 (LF & HF)

Signal to noise ratio (SNR)

>100 dB

Significant/useful number of bits

>16 bit

Scans/second

>800

Survey speed

> 130 km/h @ 5 cm point interval

Time window

388 ns (LF) / 194 ns (HF)

Bandwidth

>120%, fractional, -10 dB

Acquisition mode

Wheel, time or manual

Positioning

Wheel encoder, internal DGPS, external GPS (NMEA 0183 protocol)

Power supply

12 V Li-Ion rechargeable battery, or ext. 12 V DC source(optional)

Power consumption

1.3 A

Operating time

7 hours

Dimensions

444 x 355 x 194 mm

Weight

6.35 kg (including battery)

Operating temperature

-20° to +50°C

Environmental

IP65

Regulatory certification

CE, FCC & IC approved

Cart

Dimensions (folded for transport)

870 x 540 x 370 mm

Dimensions (when in use)

1010 x 540 x 1030 mm

Wheels

4 x Ø315 mm

12.8 kg (Cart only)¹, 20 kg (Cart, Antenna & display)²

User Interface

Display

720 x 1280 pixel or better

Operating system

Android™ (>ver. 5 Lollipop) or later

Memory

2.7 GB SDRAM or better

Processor

Intel Atom x5-Z8550, Quad-core 2.3 GHz Krait 400 or better

Recommendation

Panasonic Toughpad FZ-A2 (or equivalent)
